Epoxy food grade Coating
The exterior of a pipeline is protected from corrosion with external pipe coatings. In contrast, the pipe’s interior is protected from caustic and abrasive fluids transported through it with internal pipe linings (linings).
As a result of the internal coating in the pipeline, friction is reduced in the pipeline, and, as a result, the flow rate is improved.
Pipelines are prone to corrosion, resulting in leaks, spills, and other mishaps with disastrous results. Numerous elements, such as oxygen, chemicals, and moisture, can contribute to corrosion.
The external coating aids in shielding the pipeline from harmful elements, reducing corrosion and lengthening the pipeline’s lifespan.
The external coating offers thermal insulation, abrasion resistance, impact resistance, and corrosion protection. These characteristics aid in shielding the pipeline from harm, ensuring the contents are transported securely and effectively.
Internal Pipeline Coatings
There are two types of internal pipeline coatings: those that improve hydraulic efficiency and control corrosion. As a result, flow coatings typically applied at 2 mils don’t qualify as corrosion-resistant linings, usually around 5 mils thick.
It is possible to install 100% solids at much thicker levels than water or solvent-based coatings, close to the gap between traditional flow and corrosion-resistant coatings.
The absence of water or solvent means that 100% solids can be used as internal pipeline coatings because they increase hydraulic efficiency and prevent corrosion.
Why is the Internal Pipeline Coating Important?
Internal pipeline corrosion can reduce pipeline capacity, product contamination, and leaks, resulting in significant economic losses, environmental damage, and safety hazards. Coating the inside pipelines with a protective layer helps prevent these issues by creating a barrier between the pipeline and the transported fluids.
Epoxy food grade Coating :
Potable Water Tank Coating Food Grade, 100% Solid epoxy coating. Pipes are coated internally to prevent corrosion and to improve the product flow characteristics. The company offers coating in the form of two-part liquid epoxy systems in thickness range from 75 to 500 microns. (High Build Coating system for Potable Water Tanks (overhead & underground), pipeline, reservoirs)
Epoxy food grade is a two component food grade, solvent free coating technology formulated with special grade resin, hardener, non-toxic pigment & additives designed for permanent water contact and are an effective seamless waterproof layer. It is used for handling potable water in Pharma, food, biotechnology and drinking processing or for any application involving carrying potable water lines. It can be applied on RCC / plastered surfaces after applying appropriate primer and of course on metallic pipelines / tanks after blast cleaning.
Advantages of Epoxy food grade application
Pipeline Coatings: Areas of Application
Protective Epoxy Coatings For Oil and Gas Pipelines
Current protective coating technology for oil and gas pipelines is recognized to have both technical and economic disadvantages. Many factors contribute to the complexity of designing efficient pipeline coating formulations; climate, properties of the substrate traveling through the pipeline, product flammability and rate of flow to name a few. In addition it must be taken into consideration if the pipeline is laid underwater, under ground or above ground and the coating must be formulated to provide long term internal and external durability, the coating must be formulated with some basic tenets in mind. Some factors contributing to the complexity of this industry are briefly addressed below.
